PTFZ-08-E Omron Relay Base

240 INR/Piece

Get a Price/Quote

Product Details:

Contact Form 8 Pin Octal
Coil Voltage Relay dependent
Protect Feature Finger Protection Structure
Coil Power Relay dependent
Ambient Temperature -55C to +70C
Contact Material Relay dependent
Mechanical Life Dependent on relay specifications
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

PTFZ-08-E Omron Relay Base Price And Quantity

Minimum Order Quantity 10 Piece
Price 240 INR/Piece

PTFZ-08-E Omron Relay Base Product Specifications

Product Type Relay Base Socket
Contact Resistance Relay dependent
Theory Electromagnetic Relay Socket
Terminal Type Screw Terminal
Insulation Resistance 100 M min. (at 500 VDC)
Power Consumption N/A (relay socket)
Dimension (L*W*H) 85 mm x 35 mm x 60 mm (approx.)
Rated Voltage 250 V AC
Operate Time Varies with relay type
Usage Relay Mounting
Coil Voltage Relay dependent
Protect Feature Finger Protection Structure
Color Black
Contact Form 8 Pin Octal
Supply Terminal 8 Pin
Dielectiric Strength 2,000 VAC for 1 min between live part and ground
Mechanical Life Dependent on relay specifications
Size Standard DIN Rail Mount
Working Temperature -55C to +70C
Coil Power Relay dependent
Ambient Temperature -55C to +70C
Contact Material Relay dependent
Weight Approx. 90 g
Contact Load Depends on relay used

PTFZ-08-E Omron Relay Base Trade Information

Payment Terms Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque
Supply Ability 500 Piece Per Day
Delivery Time 1 Days
Sample Policy Sample costs shipping and taxes has to be paid by the buyer
Main Export Market(s) Asia
Main Domestic Market All India
Certifications YES

Product Description

Socket, DIN rail/surface mounting, 8-pin, screw terminals: G3H, LY1, LY2

Product details

Material	Plastic
Usage/Application	Control Panels
Model Name/Number	PTFZ-08-E
Relay Type	General Purpose Relays

Versatile Mounting Options

The PTFZ-08-E relay base is adaptable to both DIN rail and panel mounting, streamlining installation within diverse control systems. Its standard size allows seamless integration into existing panels, promoting efficient workflow and system upgrades without significant infrastructure adjustment.

Reliable Electrical Performance

Engineered with high-quality heat-resistant resin, the base ensures superior safety and durability. It withstands up to 2000 VAC for one minute between live part and ground and provides insulation resistance over 100 M at 500VDC, supporting robust protection and long life in demanding environments.

Easy and Secure Connections

Wire connections are achieved through convenient screw clamp terminals, incorporating M3 screws to ensure a stable fit. The optional relay retaining clip enhances operational security, preventing unintentional relay disconnection during mechanical vibrations or maintenance procedures.

FAQ's of PTFZ-08-E Omron Relay Base:

Q: How do I install the PTFZ-08-E Omron Relay Base on a DIN rail or panel?

A: To install the PTFZ-08-E relay base, position it onto the standard DIN rail and secure using the base clip, or affix it to a panel with appropriate screws. Ensure wire connections via the screw clamp terminals for a reliable setup.

Q: What types of relays are compatible with the PTFZ-08-E relay socket?

A: The base is compatible with Omron LY and MY series 8-pin relays. Check the relay specifications for optimal performance and ensure the pin configuration matches the socket for reliable operation.

Q: When should I use the optional relay retaining clip?

A: The relay retaining clip should be used when additional physical security is required, such as applications subject to vibration, regular maintenance, or where accidental relay removal must be prevented.

Q: Where can the PTFZ-08-E relay base be effectively used?

A: This relay base is well suited for industrial automation, control panels, and electrical equipment, particularly where safe, durable, and secure relay mounting is essential.

Q: What are the benefits of the flame retardant UL94V-0 body material?

A: The UL94V-0 rating ensures the base resists ignition and halts flame spread, enhancing overall equipment safety and reliability in high-temperature or critical environments.

Q: How does the screw terminal connection process work for wiring?

A: Simply strip the wire, insert it into the screw clamp terminal, and tighten the M3 screw to secure. This method provides stable, vibration-resistant connections crucial for industrial systems.

Q: What protection features does the PTFZ-08-E base offer?

A: It features a finger protection structure to prevent accidental contact with live terminals and robust electrical insulation, supporting safe handling and installation.
