OMRON V- SERIES (MICRO SWITCH) V-104-1A5

330 INR/Piece

Get a Price/Quote

Product Details:

Max. Current 16 Ampere (amp)
Number of Module 1
Circuit Type SPST-NO
Automation Grade Manual
Mechanical Life 10,000,000 operations min.
Protection Level IP40
Temperature Range -25C to +80C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

OMRON V- SERIES (MICRO SWITCH) V-104-1A5 Price And Quantity

Price 330 INR/Piece
Minimum Order Quantity 10 Piece

OMRON V- SERIES (MICRO SWITCH) V-104-1A5 Product Specifications

Rated Voltage 250 VAC
Current Rating 16 A at 250VAC
Protection Level IP40
Temperature Range -25C to +80C
Max. Voltage 220 Volt (V)
Mounting Type Panel Mount, Screw Mount
Finish Type Matte
Contact Resistance 15 m max. (initial)
Circuit Type SPST-NO
Response Time < 5 ms
No Of Poles Single Pole
Max. Current 16 Ampere (amp)
Material Thermoplastic resin (housing), Silver alloy (contacts)
Number of Module 1
Automation Grade Manual
Product Type OMRON MICRO SWITCH
Mechanical Life 10,000,000 operations min.
Size Standard
Operating Temperature -25C to +80C (with no icing or condensation)
Stoke 2.8 mm (total travel)
Color black
Weight About 7g
Insulation Resistance 100 M min. (at 500 VDC)

OMRON V- SERIES (MICRO SWITCH) V-104-1A5 Trade Information

Payment Terms Cash Advance (CA), Cash in Advance (CID), Cheque, Paypal
Supply Ability 100 Piece Per Week
Delivery Time 7 Days
Sample Policy Sample costs shipping and taxes has to be paid by the buyer
Main Domestic Market All India
Certifications YES

Product Description

Experience the acclaimed reliability of the OMRON V-SERIES (MICRO SWITCH) V-104-1A5. This highly recommended micro switch features a robust hinge lever actuator, quick-connect terminals, and a wondrous mechanical life of at least 10,000,000 operations. With a current rating of 16A at 250VAC and an unbeatable response time (<5 ms), it is trusted for both durability and precision. Its incomparable insulation resistance (100 M min.) and IP40 protection ensure operational stability in demanding environments, making it a featured switch for automation specialists. Black thermoplastic resin housing and silver alloy contacts further elevate its performance to new heights.

Exceptional Versatility for Diverse Applications

The OMRON V-104-1A5 micro switch is particularly suitable for use in industrial control panels, home appliances, and automation assemblies. Its sturdy design and standard size allow seamless integration in panel and screw mount applications. It excels in areas such as machinery safety controls, vending machines, and office equipment. This acclaimed device meets the rigorous demands of distribution, exporting, and trading sectors, making it an incomparable solution for both OEM and after-market usage worldwide.

Professional Trading Terms & Prime Accessibility

Benefit from premium trading terms when sourcing the OMRON V-104-1A5. With availability at major FOB ports, sample options enhance confidence ahead of commitment. Payment terms are designed to manage your expenditure efficiently while keeping the list price competitive in the global market. Distributors and exporters enjoy an unbeatable advantage with easy access, thorough documentation, and fast, reliable deliveries from leading Japanese manufacturers.

FAQ's of OMRON V- SERIES (MICRO SWITCH) V-104-1A5:

Q: How does the OMRON V-104-1A5 enhance operational reliability?

A: The OMRON V-104-1A5 ensures operational reliability through its mechanical life of at least 10 million cycles and a minimum electrical life of 50,000 operations at rated load, minimizing maintenance needs.

Q: What are the use cases for the V-104-1A5 micro switch?

A: This switch is highly suitable for industrial automation, appliance safety controls, vending machines, and various control panels, offering dependable performance in diverse environments.

Q: Where can the OMRON V-104-1A5 be installed?

A: The device supports panel and screw mounting, making it versatile for installation in machinery, control cabinets, and equipment designed for SPST-NO micro switches.

Q: What is the process to request a sample of this micro switch?

A: Samples are available upon request through authorized distributors or exporters. Simply contact your supplier, specify your requirements, and arrange for delivery as per their terms.

Q: Which benefits distinguish this micro switch in demanding industries?

A: Its unbeatable response time, high current rating, robust insulation resistance, and mechanical durability make it incomparable for applications that demand consistent, safe, and long-lasting switch operation.

Q: How does the switch's payment and purchasing structure support businesses?

A: With flexible payment terms and competitive list pricing, businesses can manage expenditures efficiently while securing premium, acclaimed switching components for their operations.
