Omron limit switch D4E-1A00N

2752 INR/Piece

Get a Price/Quote

Product Details:

Automation Grade Automatic
Temperature Range -10C to +80C
Response Time 20 ms max.
Mechanical Life 10,000,000 operations min.
Protection Level IP67
Max. Current 5A
Finish Type Standard
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Omron limit switch D4E-1A00N Price And Quantity

Price 2752 INR/Piece
Minimum Order Quantity 1 Piece

Omron limit switch D4E-1A00N Product Specifications

No Of Poles 1
Stoke Short stroke plunger type
Contact Resistance 25 m max.
Mounting Type Panel/Surface Mount
Response Time 20 ms max.
Current Rating 5A at 250 VAC
Automation Grade Automatic
Weight About 29g
Temperature Range -10C to +80C
Color Gray / Black
Rated Voltage 250 VAC, 30 VDC
Max. Voltage 250 VAC
Finish Type Standard
Product Type Limit Switch
Circuit Type SPDT (Single Pole Double Throw)
Number of Module Single
Size 30.5 mm x 16 mm x 20 mm
Insulation Resistance 100 M min. (at 500 VDC)
Protection Level IP67
Mechanical Life 10,000,000 operations min.
Material Plastic/Metal
Operating Temperature -10C to +80C
Max. Current 5A

Omron limit switch D4E-1A00N Trade Information

Delivery Time 1 Days
Sample Available Yes
Packaging Details Ready stock
Main Domestic Market All India

Product Description

Small Sealed limit Switch,Compact Switch,Enclosed Limit switches, General load, IP67, SPDT, Roller plunger, Panel mounting/Side-mounting.

We are authorized channel partner, dealers, distributors, suppliers for OMRON, PANASONIC, FUJI ELECTRIC, PHOENIX CONTACT, FESTO, CANON, SUPVAN, EPSON ROBOTS and Super Stockiest, Wholesalers for MITSUBISHI ELECTRIC, PROFACE, BANNER, SCHNEIDER ELECTRIC, SIEMENS, MEANWELL, AUTONICS, DELTA, SICK Etc.

Note : We are also Importers and Exporters for all Industrial Automation products along with manufacturers of Electrical Control Panels.

Reliable Operation Across Applications

Engineered for demanding environments, the D4E-1A00N maintains reliable performance with high shock and vibration resistance. Its sturdy construction and IP67 rating make it ideal for machine automation, conveyors, and safety interlocks. The short stroke plunger and rapid response ensure accurate limit detection even in fast-paced systems, contributing to superior automation efficiency.

Robust Design and Versatile Mounting

This limit switch offers flexible mounting options-panel or surface-with a compact footprint (30.5 mm x 16 mm x 20 mm). Combining plastic and metal materials, it is both lightweight (about 29g) and durable. Its standard finish and automatic circuit operation fit seamlessly into diverse setups, while the gray/black housing complements industrial aesthetics.

FAQ's of Omron limit switch D4E-1A00N:

Q: How do I install the Omron D4E-1A00N limit switch for optimum performance?

A: The switch supports both panel and surface mounting. For precise installation, follow the recommended panel cutout dimensions specified in the datasheet and ensure the actuator's stroke aligns with your intended detection point. Secure the switch using mounting screws and make proper electrical connections to the SPDT terminals for reliable operation.

Q: What are the benefits of using the pin plunger actuator type in automated systems?

A: A pin plunger actuator provides exact position sensing with a short stroke (0.5 mm max. pretravel, 2 mm min. overtravel), suitable for applications demanding rapid response and precise limit detection. Its construction ensures high durability, making the switch a reliable component in repetitive machine cycling.

Q: When is it suitable to use this limit switch regarding operating environment?

A: This switch is ideal for environments that demand resistance to water, dust, vibrations, and shocks, with operational temperatures ranging from -10C to +80C and IP67 protection. Use it in industrial automation, machinery, or outdoor control panels requiring robust and stable limit detection.

Q: Where can I source the Omron D4E-1A00N limit switch?

A: The D4E-1A00N is available through authorized distributors, exporters, suppliers, or traders specializing in Japanese automation products. For genuine parts and technical support, consult official Omron dealers or trusted industrial electronics stores.

Q: What is the process for connecting the electrical terminals of the D4E-1A00N?

A: Connect the 1NO+1NC terminals as per your circuit configuration, ensuring voltage and current do not exceed 250 VAC and 5A respectively. Confirm wire insulation and terminal tightness for safety. Refer to the datasheet for terminal locations and wiring diagrams for proper integration into your control system.

Q: How does the limit switch ensure stable operation during shocks and vibrations?

A: The switch is designed to withstand vibration frequencies between 10 to 55 Hz at a 1.5-mm double amplitude and shock forces up to 1,000 m/s2 (approx. 100 G). Its robust build, coupled with high dielectric and insulation resistance, prevents contact failure and maintains consistent operation even under mechanical stress.

Q: What long-term benefits does the D4E-1A00N offer for industrial automation?

A: With a mechanical life exceeding 10 million cycles and an electrical life of at least 500,000 operations, the D4E-1A00N reduces downtime and maintenance costs over time. Its fast response, reliability in harsh environments, and flexible mounting options make it a cost-effective choice for continuous industrial operation.
