OMRON CJ-SERIES PLC (Serial Communications Units) CJ1W-SCU22
62778 INR/Thousand
Product Details:
- Application Programmable Logic Controller (PLC) Serial Communication for Industrial Automation
- Features 2 Serial Ports, Configurable Communication Protocols, LED Status Indicators
- Remote Control Yes
- Phase Single Phase
- Mounting Type DIN Rail Mounting
- Cable Length Dependent on Serial Interface (max. 15 m for RS-232C)
- Automation Grade Automatic
- Click to View more
X
OMRON CJ-SERIES PLC (Serial Communications Units) CJ1W-SCU22 Price And Quantity
- 62778.00 - 96583.00 INR/Thousand
- 1 Piece
- 62778 INR/Thousand
OMRON CJ-SERIES PLC (Serial Communications Units) CJ1W-SCU22 Product Specifications
- Programmable Logic Controller (PLC) Serial Communication for Industrial Automation
- Operating: 0C to 55C, Storage: -20C to 75C
- 2 Serial Ports, Configurable Communication Protocols, LED Status Indicators
- Plastic and Metal (Industrial Grade)
- Yes
- Supplied from PLC Backplane
- DIN Rail Mounting
- Single Phase
- Dependent on Serial Interface (max. 15 m for RS-232C)
- RS-232C and RS-422/485 Ports
- Depends on Main PLC Power Supply
- Up to 115.2 kbps (Baud Rate)
- Automatic
- 50/60 Hz
- Not Applicable (Module for PLC CPU Expansion)
- Digital
- IP20
- Approx. 180 g
- 24V DC (from Backplane)
Product Description
PLC Serial Communications unit Card, 2 nos RS-232C ports type, High speed Model type.
We are authorized channel partner, dealers, distributors, suppliers for OMRON, PANASONIC, FUJI ELECTRIC, PHOENIX CONTACT, FESTO, CANON, SUPVAN, EPSON ROBOTS and Super Stockiest, Wholesalers for MITSUBISHI ELECTRIC, PROFACE, BANNER, SCHNEIDER ELECTRIC, SIEMENS, MEANWELL, AUTONICS, DELTA, SICK Etc.
Note : We are also Importers and Exporters for all Industrial Automation products along with manufacturers of Electrical Control Panels.
| Usage/Application | Industrial |
| Brand | OMRON |
| Mounting Type | DIN Rail |
Versatile Serial Communication Options
The CJ1W-SCU22 unit provides two independent serial ports that can be flexibly configured as RS-232C or RS-422A/485, making it suitable for diverse industrial networking requirements. With support for multiple protocols, including Host Link and user-defined types, it ensures seamless integration with various devices on your shop floor.
Robust Design with Industrial-Grade Isolation
Featuring photocoupler isolation between the PLC and communication lines, the CJ1W-SCU22 safeguards your system against electrical interference. Its sturdy construction with plastic and metal elements, alongside DIN rail mounting, ensures durability and reliable performance in challenging industrial environments.
Easy Monitoring and Integration
Equipped with unit status and port status LEDs, the CJ1W-SCU22 offers at-a-glance indication of operational states. Designed for use with Omron CJ-series and CS-series controllers, this module simplifies system expansion, enhancing the communication capabilities of your programmable automation setup.
FAQ's of OMRON CJ-SERIES PLC (Serial Communications Units) CJ1W-SCU22:
Q: How do I configure the serial ports on the OMRON CJ1W-SCU22 module?
A: Each serial port on the CJ1W-SCU22 can be set as either RS-232C or RS-422A/485 using software configuration options available in Omron's PLC programming tools. This allows users to adjust communication settings as per their device requirements.Q: What protocols can be used with the CJ1W-SCU22 Serial Communications Unit?
A: The CJ1W-SCU22 supports Host Link, NT Link, proprietary Omron, and user-defined communication protocols, offering flexibility for integration with various industrial devices and systems.Q: When should I consider using the CJ1W-SCU22 module in my PLC system?
A: The CJ1W-SCU22 is ideal when your automation system requires serial communication with multiple external devices, such as HMIs, barcode readers, or other controllers, and when your application demands flexible protocol support and reliable isolation.Q: Where is the CJ1W-SCU22 typically installed within a control system?
A: The CJ1W-SCU22 is installed into the expansion slot of Omron CJ-series or CS-series PLCs and mounted on a DIN rail within industrial control panels for centralized, secure operation.Q: What is the process for monitoring the communication status of the CJ1W-SCU22?
A: You can observe communication status via the unit's LED indicators, which display operational and port activity status, ensuring quick diagnostics and easier maintenance.Q: How does the CJ1W-SCU22 benefit industrial automation applications?
A: By offering two configurable serial channels, protocol flexibility, and robust isolation, the CJ1W-SCU22 expands the connectivity options for your PLC, enabling enhanced data exchange and integration, which increases system efficiency and adaptability.Tell us about your requirement
