LY1N-D2 DC24
200 INR/Piece
Product Details:
- Contact Resistance 50m Max.
- Contact Material Silver Alloy
- Coil Voltage 24V DC
- Protect Feature Sealed
- Power Consumption About 0.9W
- Ambient Temperature -40C to +55C
- Mechanical Life 10,000,000 operations min.
- Click to View more
X
LY1N-D2 DC24 Price And Quantity
- 100 Piece
- 200 INR/Piece
LY1N-D2 DC24 Product Specifications
- Electromagnetic Relay
- Sealed
- 24V DC
- Silver Alloy
- Black and Clear
- 50m Max.
- About 28 x 21.5 x 36mm
- Electromagnetic Relay
- 10A 250V AC/ 10A 30V DC
- 100M min. (at 500VDC)
- Screw Terminal
- DC24V
- Approx. 95g
- -40C to +70C
- General Purpose
- Approx. 0.9W
- 1500VAC, 50/60Hz for 1 min
- Less than 20ms
- 10,000,000 operations min.
- Plug-in
- DPDT (Double Pole Double Throw)
- Standard
- -40C to +55C
- About 0.9W
- Control Panels, automation, industrial machinery
- 10A
- DIN Rail or Panel Mount
- LY1N-D2 DC24
- 1800 operations/hour (mechanical)
- 20ms max. (Operate), 20ms max. (Release)
- -40°C to +85°C
LY1N-D2 DC24 Trade Information
- Cash in Advance (CID)
- Asia
- All India
Product Description
Relay, plug-in, 5-pin, SPDT, 15 A, LED indicator, 1 pole/channel coil suppression, 24 VDC
Product details
| Material | Glass |
| Usage/Application | Control Panels |
| Model Name/Number | LY1N-D2 DC24 |
| Number Of Poles | 2 Pole |
Versatile Mounting and Durable Design
The LY1N-D2 DC24 relay provides great versatility with both DIN rail and panel mounting capabilities. Its robust, sealed construction, black and clear housing, and plug-in screw terminals ensure secure connections and easy installation. These features make it particularly suitable for a wide range of industrial automation and control panel applications.
Reliable Performance Across Environments
With a wide operating temperature range from -40C to +70C and storage tolerance up to +85C, the LY1N-D2 DC24 excels in diverse environments. Its high mechanical life-over 10 million operations-coupled with swift cycle times and strong dielectric strength, guarantees consistent performance even under challenging conditions.
Efficient and Safe Operation
Offering a rated current of 10A and high insulation resistance, this relay is well-protected and energy efficient, drawing only about 0.9W. The use of silver alloy contacts ensures low resistance and high durability, making the LY1N-D2 a dependable choice for both distributor networks and end users seeking reliable automation solutions.
FAQ's of LY1N-D2 DC24:
Q: How do I install the LY1N-D2 DC24 relay in my control panel?
A: The LY1N-D2 DC24 relay supports both DIN rail and panel mounting. Simply choose the desired mounting method, secure the relay accordingly, and use the plug-in screw terminals to connect your wiring. Installation is straightforward, allowing for quick integration in control panels and automation setups.Q: What are the main benefits of using the LY1N-D2 DC24 in industrial applications?
A: The LY1N-D2 DC24 offers high reliability, fast operate and release times (<20ms), long mechanical life (minimum 10 million operations), and robust sealed construction. Its versatile mounting options and low power consumption make it especially suited for demanding environments in industrial automation and machinery.Q: When should I consider using a relay with a rated current of 10A and DPDT contacts?
A: Choose the LY1N-D2 DC24 when you need to control circuits with current up to 10A, or require a double pole, double throw (DPDT) configuration to simultaneously control two independent circuits. It is effective for switching both AC and DC loads, making it ideal for automation tasks and general-purpose switching.Q: Where can the LY1N-D2 DC24 relay operate effectively?
A: This relay is designed to work reliably in a variety of environments, with an ambient temperature range of -40C to +55C and operation up to 70C. Its robust build allows for dependable performance in factories, machinery rooms, and electrical control cabinets.Q: What is the process for replacing or maintaining the LY1N-D2 DC24 relay?
A: Thanks to its plug-in design, the LY1N-D2 DC24 can be easily replaced without disturbing wiring. Power off the system, unplug the old relay, insert the new unit, and restore power. Regular inspection ensures optimal performance, but its high mechanical life minimizes maintenance needs.Q: How does the sealed construction benefit the relay and its application?
A: The sealed design of the LY1N-D2 DC24 protects the internal components from dust, moisture, and other contaminants. This enhances the relay's durability and reliability, especially in industrial and harsh operating environments.Tell us about your requirement
