Basic Limit Switch Z-15GQ2255-B

1034 INR/Piece

Get a Price/Quote

Product Details:

Rated Voltage 220V AC/DC
Number of Module Single
Protection Level IP65
Max. Current 15A
Finish Type Standard
Response Time 10 ms max.
Automation Grade Manual/Automatic
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Basic Limit Switch Z-15GQ2255-B Price And Quantity

Minimum Order Quantity 10 Piece
Price 1034 INR/Piece

Basic Limit Switch Z-15GQ2255-B Product Specifications

Protection Level IP65
Max. Voltage 220 Volt (V)
Max. Current 15A
Number of Module Single
Rated Voltage 220V AC/DC
Current Rating 15A
Mounting Type Panel Mount
Contact Resistance 15m max. (initial)
Finish Type Standard
Automation Grade Manual/Automatic
Response Time 10 ms max.
Temperature Range -25C to +80C
No Of Poles 1
Color Black
Operating Temperature -25C to +80C
Material Fiber & Brass
Insulation Resistance 100M min (at 500 VDC)
Stoke Full Stroke Operation
Mechanical Life 10,000,000 operations min.
Size Standard
Weight Approx. 60g
Product Type Basic Limit Switch Z-15GQ2255-B
Circuit Type SPDT (Single Pole Double Throw)

Rated Frequency 50/60 Hz
Actuator Type Short Hinge Roller Lever
Body Material High-grade fiber and brass
Shock Resistance Malfunction: 300 m/s
Insulation Category Class II
Dielectric Strength 1000V AC for 1 minute between non-continuous terminals
Ambient Humidity 35%85% RH
Wire Connection Screw terminals
Vibration Resistance Malfunction: 10-55Hz, 1.5mm double amplitude
Contact Configuration 1NO + 1NC

Basic Limit Switch Z-15GQ2255-B Trade Information

Supply Ability 1000 Piece Per Week
Delivery Time 7 Days

Product Description

Capitalise on the top-rated Basic Limit Switch Z-15GQ2255-B, designed with an unmatchable blend of valorous engineering and optimum performance. This switch comes equipped with a 1NO + 1NC contact configuration, a robust short hinge roller lever actuator, and high-grade fiber and brass construction to ensure lasting resilience. Operating efficiently at 220V AC/DC with a 15A current rating, it guarantees reliable execution even in demanding environments. The IP65 protection level secures your automation, while its wide temperature range and outstanding mechanical life mark it as a quintessential investment for diverse industrial applications.

Primary Competitive Advantages and Versatile Applications

The Basic Limit Switch Z-15GQ2255-B stands out due to its high durability, IP65 protection, and long mechanical life of 10 million operations. Its valorous build quality makes it optimum for automated machinery, conveyors, and safety interlocks. The switch is suitable for use in both manual and automated control systems, across industries such as manufacturing, packaging, and robotics. Enhanced with precise response time, it offers unmatchable reliability for critical processes.

Certifications, Export Market Focus, and Packaging Details

Certified to meet strict industrial standards, the Z-15GQ2255-B is frequently supplied to Japan's thriving export market, catering to global demands. Packaging ensures safe and secure exchange, with every unit meticulously sealed for protection during supply and distribution. The product is widely exchanged and supplied within all major domestic markets, supported by leading distributors, exporters, and suppliers. This ensures swift delivery and trustworthy performance in varied applications.

FAQ's of Basic Limit Switch Z-15GQ2255-B:

Q: How does the Z-15GQ2255-B limit switch ensure operational safety in automation systems?

A: The Z-15GQ2255-B features unmatchable dielectric strength, IP65 protection, and robust contact configuration (1NO + 1NC), helping prevent malfunctions and enhance user safety in automated processes.

Q: What makes the construction of the Z-15GQ2255-B optimum for industrial environments?

A: Made from high-grade fiber and brass with a standard finish, the switch offers outstanding durability, resistance to vibration, and reliable performance in environments with temperatures from -25C to +80C.

Q: Where is the Basic Limit Switch Z-15GQ2255-B commonly used?

A: This switch is commonly used across manufacturing, packaging, conveyor systems, and robotics, excelling in both manual and automatic operation due to its versatile actuator and circuit type.

Q: When should I consider using the Z-15GQ2255-B in my application?

A: Consider the Z-15GQ2255-B when reliability, rapid response time, and robust mechanical life are vital-especially in automated or safety-critical systems requiring an export-quality, valorous control solution.

Q: What is the process for wiring the Z-15GQ2255-B limit switch?

A: The switch uses screw terminals for wire connection, enabling straightforward installation and secure attachment, suitable for panel mount applications by distributors, exporters, suppliers, and traders.
